| Measure range | PH(0~14PH); ORP(-2000MV~+2000MV) |
| Accuracy | ±0.02PH;1MV |
| Resolution | 0.01PH;1MV |
| Input resistance | 10^12Ω |
| Temp range | -10~130℃;Pt1000/NTC10K |
| Signal output | 4~20mA output Maximum loop500Ω |
| Power supply | AV220V±10%;50Hz/60Hz |
| Relay out | (90~260)VAC |
| Working temp | 0-60℃ |
| RS485 | Modbus-RTU |
| Alarm | 2, AC250V/3A |
| Record | 500,000 data |
| Dimension | 101mm×105mm×128mm |
| Weight | 0.85Kg |
Sinomeasure is committed to industrial process automation sensors and instrument since its establishment for decades. The main products are water analysis instrument, recorder, pressure transmitter, flowmeter and other field instruments.
