Introduction
This product has a 18-channel analog signal input channel, 4-channel relay alarm output channel, 1-channel150mA distribution output channel,1-channel RS-485 communication interface ,and a USB data dump interface.This product has online firmware upgrade function, which can be done through a USB flash drive or 485 interface. It supports customized writing of the startup interface and screenshot display function.
-
Parameters
| Product | Paperless recorder |
| Model | RN3000 |
| Screen size | 3.5-inch TFT true color LCD screen. Resolution is 320 * 240 High definition LED backlight. |
| Dimension | Dimension：96mm×96mm×100mm Cutout dimension：92mm×92mm |
| Panel thickness | 1.5mm~6.0mm |
| Weight | 0.37kg |
| Power supply | (85~264)VAC，(47~63)Hz (24VDC can be customized) |
| Internal storage | 64M Bytes Flash (96M,128M can be customized) |
| External storage | U disk support (standard USB2.0 communication interface) |
| Maximum power consumption | 10W |
| Relative humidity | (10~85)%(No condensation) |
| Operating temperature | (0~50)℃ |
| Storage conditions | Temperature: (-20~60)℃ Relative humidity: (5~95)%RH(No condensation) |
