Specification
| Product | Multi-loop digital display controller |
| Model | SIN-2700 |
| Dimension | A. 160*80*136mm B. 80*160*136mm C. 96*96*136mm |
| Measurement accuracy | ±0.2%FS |
| Transmission output | Analog output----4-20 mA, 1-5v、 0-10mA, 0-5V, 0-20mA, 0-10V |
| Alarm Output | Over-range display value flashing alarm function With upper and lower limit alarm function, with alarm return difference setting; Relay capacity： AC220V/2A(big)DC24V/2A(big) (Resistive load) Note: When the load exceeds the relay contact capacity, please do not directly carry the load |
| Power supply | AC/DC100~240V (Frequency 50/60Hz) Power consumption≤5W DC 20~29V Power consumption≤3W |
| Use environment | Operating temperature (-10~50℃) No condensation, no icing |
| Printout | RS232 printing interface, micro-matched printer can realize manual, timing and alarm printing functions |
-
Introduction
The SIN-2700 digital display controller is a versatile electronic instrument for monitoring and controlling industrial processes. It features a microprocessor, digital display, and multiple input/output terminals, supporting parameters such as temperature, pressure, flow, and humidity. The controller processes signals from sensors and displays real-time feedback for precise process management. With user-friendly operation, programmability, and compatibility with remote monitoring systems, the SIN-2700 offers high precision, reliability, and flexibility across a wide range of automation and industrial applications.
