Specification
| Product | Signal generator |
| Model | SIN-C703S |
| Operating temperature and humidity | -10~55℃, 20~80% RH |
| Storage temperature | -20-70℃ |
| Size | 115x71x30(mm) |
| Weight | 143g |
| Power | 4*AAA batteries or external 5 V/1A adapter |
| Power dissipation | About 200 mA; with power supplied by 4*AAA batteries (each nominal capacity of 1100 mAh ), can be used for 4 hours with a full load and 17 hours standing by. |
| OCP | 30V |
-
Introduction
-
Features
-
Sources and reads mA, mV, V, Ω, RTD and TC
-
Keypad to enter output parameters directly
-
Concurrent input / output, convenient to operate
-
Sub display of sources and reads (mA, mV, V)
-
Large 2-line LCD with backlight display
-
24 VDC loop power supply
-
Thermocouple measurement / output with automatic or manual cold junction compensation
-
Corresponds to various types of source pattern (Step sweep/Linear sweep/Manual step)
