Specification
| Product | Gas Turbine Flow Meter |
| Model | SIN-LWGY |
| Diameter Nominal | DN4~DN200 |
| Response time | 20ms(5s meter head without display) |
| Accuracy | Level 0.5/1.0 |
| Medium viscosity | Less than 5×10-6m2/s(>5×10-6m2/s, the flowmeter should be calibrated with standard solution before use) |
| Medium Temperature | Regular model:-20℃~+80℃; High temperature:-20℃~+120℃ |
| Ambient temperature | -20℃~+60℃ |
| Storage temperature | 5°C~40°C |
| Relative humidity | 5% to 90% |
| Power Supply | 3.6V lithium battery; 12V DC; 24VDC |
| Output Signal | Pulse signal, 4~20mA current signal、Modbus |
| Protection level | IP65(IP67, IP68 available upon negotiation, pulse head is IP00) |
-
Introduction
SIN-LWGY turbine flowmeter is a kind of speed instrument, which has the advantages of high accuracy, good repeatability, simple structure, small pressure loss and convenient maintenance. It is used to measure the volume flow of low viscosity liquid in closed pipe.
-
