Specification
| Product | Turbine flow meter |
| Model | SIN-LWGY |
| Diameter Nominal | DN4~DN200 |
| Repeatability | 1/3 of the accuracy grade |
| Accuracy | Level 0.5/1.0 |
| Medium viscosity | Less than 5×10-6m2/s(>5×10-6m2/s, the flow meter should be calibratedwith standard solution before use) |
| Medium Temperature | Regular model:-20℃~+80℃; High temperature:-20)℃~+120℃ |
| Ambient temperature | -20℃~+60℃ |
| Relative humidity | 5% to 90% |
| Response time | 20ms(5s meter head without display) |
| Power Supply | 3.6V lithium battery; 12V DC; 24VDC |
| Output Signal | Pulse signal, 4~20mA current signal, Modbus |
| Ingress protection | IP65(IP67, IP68 available upon negotiation,pulse head is IP00) |
-
Introduction
SIN-LWGY series liquid turbine flowmeter is a kind of speed instrument, which has the advantages of high accuracy, good repeatability, simple structure, small pressure loss and convenient maintenance. It is used to measure the volume flow of low viscosity liquid in closed pipe.
-
