Specification
| Product | Vortex flow meter |
| Model | SIN-LUGB |
| Wafer connection | DN15-DN300 (priority PN2.5MPa) |
| Flange connection | DN15-DN50 (priority PN2.5MPa) |
| DN65-DN200 (priority PN1.6MPa) | |
| DN250-DN300 (priority PN1.0MPa) | |
| Accuracy | 1.0% 1.5% |
| Range Ratio | 1:8 |
| Medium Temperature | -40℃~+150℃，-40℃~+260℃，-40℃~+300℃ |
| Power Supply | 24VDC±5%, lithium battery 3.6V |
| Current output | 2-wire (4~20) mA, load resistance ≤ 300 Ω (including wire resistance) |
| Communication interface | RS485, HART |
| Body Materials | Stainless steel |
| Ingress protection | IP65 |
| Display Language | English, Chinese |
-
Introduction
SIN-LUGB Vortex flow meter work on the principle of generated vortex and relation between vortex and flow by theory of Karman and Strouhal, which specialize in measurement of steam, gas and liquid of lower viscosity.
-
