Specification
| Product | Dual-loop digital display controller |
| Model | SIN-2200 |
| Display | Dual-screen LED display |
| Dimension | A.160*80*110mm B. 80*160*110mm C. 96*96*110mm D. 96*48*110mm E. 48*96*110mm F. 72*72*110mm K. 160*80*110mm L. 80*160*110mm |
| Measurement accuracy | ±0.2%FS |
| Transmission output | Analog output----Analog output----4-20mA、1-5v、 0-10mA、0-5V、0-20mA、0-10V |
| Alarm Output | ALM---With upper and lower limit alarm function, with alarm return difference setting；Relay contact capacity： AC125V/0.5A(small)DC24V/0.5A(small)（Resistance C load） AC220V/2A(big)DC24V/2A(big)（Resistive load） Note: When the load exceeds the relay contact capacity, please do not directly carry the load |
| Power supply | AC/DC100~240V (Frequency50/60Hz) Power consumption≤5W DC 12~36V Power consumption≤3W |
| Use environment | Operating temperature（-10~50℃）No condensation, no icing |
| Printout | RS232 printing interface, micro-matched printer can realize manual, timing and alarm printing functions |
-
Introduction
The dual-loop digital display controller features automatic SMD packaging and strong anti-interference performance. It works with various sensors and transmitters to measure and display temperature, pressure, level, speed, force, and other physical parameters, while supporting alarm outputs, analog signals, and RS-485/RS-232 communication. The dual-LED display allows independent upper and lower screen settings, and built-in mathematical functions enable addition, subtraction, multiplication, and division of the two loop inputs, providing versatile applicability.
